Description du produit
Epoxy coated wire mesh is composed of low carbon steel wires woven together and coated with epoxy resin making this resistant to corrosion and acids. It is mainly used in hydraulic or air filters as the supporting layers, it is the main part of the filters.It can also be used in windows and doors as insect screen. The epoxy coating can be applied to Plain Steel Wire Mesh, Aluminum Wire Mesh or Stainless Steel Wire Mesh.
In many fields it can be used in replacement of traditional mesh, particularly for replacing of SS wire mesh and Galvanized wire cloth with economic, eco-friendly and durable advantages.
Spécification de produit
Epoxy Wire Mesh Specifications
| No. | Substrate material | coating | specification | (mm)width | (m)length | Applied industry |
| 1 | Q195 | Black color &Oil resistance | 18x14/0.18 | 20mm-1250mm | 30m-914m | hydraulics |
| 2 | Q195 | Black color &oil resistance | 18x14/T0.18 | 20mm-1250mm | 30m-914m | hydraulics |
| 3 | Q195 | Black color &Oil resistance | 12x10/0.254 | 50mm-1250mm | 30-914m | hydraulics |
| 4 | Q195 | Black color &Oil resistance | 22x20/0.18 | 20mm-1250mm | 30m-914m | hydraulics |
| 5 | Q195 | White color &Oil resistance | 18x14/0.18 | 20mm-1250mm | 30m-914m | hydraulics |
| 6 | 5154A(H39) | Gray color &weatherproof | 17x15/0.26 | 20mm-1250mm | 30m-914m | air filtration |
| 7 | 5154A(H39) | Black color &Oil resistance | 18x14/0.21 | 20mm-1250mm | 30m-914m | hydraulics |
| 8 | 5154A(H39) | Black color &weatherproof | 18x15/0.28 | 20mm-1250mm | 30m-914m | window screen |
détails du produit
type de produit:
Usage: Filters
Material:Low Carbon Steel Wire, Stainless Steel Wire and Aluminum Alloy Wire
Woven Style: Plain Weave
Mesh: 16x16, 18x16,18x18,18x14,26x22,24x24,30x30
Diameter:BWG30,31,32,33,34,35,36,37,38,39.
Packing: Inner kraft paper, outside plastic cloth, packed in wooden pallet or case
Product Feature
Oil Immersion Rust Proof
Strong Adhesion
Weatherproof
Light Weight & Easy to Clean
Soft& Easy to Shaped Structure
Corrosion Properties
Even Aperture
Flexibility
Product Packing & Shipping
1. The mesh is rolled onto the paper tube
2. First wrap the mesh in kraft paper then plastic film
3. Finally pack the mesh rolls in the wooden pallet or case.
